GRAPHTEC FC6000 Series
Technical Specifications






CPU 32 bit CPU
Configuration Gift Rolling Type
Drive method Digital Servo Drive
Maximum Cutting area (W x L) 375mm x 50m +1 603mm x 50m +1 1213mm x 50m +1
Cutting area guaranteed accuracy (W x L) (when using the basket) 356mm x 2m +1 584mm x 2m +1 1194mm x 2m +1
584mm x 5m +1 584mm x 5m +1
Mountable Media Width Max 484mm Max 712mm Max 1346mm
Min 50mm Min 50mm Min 120mm
Number of push roller 2 roller 2 roller 3 roller 4roller
Maximum cutting speed 600mm/s(all direction) 900mm/s(45 direction) 1000mm/s(45 direction)
Maximum Acceleration 21.2m/s2(45 direction) 13.9m/s2(45 direction)
Maximum guaranteed cutting force 2.94 N (300gf) in 31 steps 4.41 N (450gf) in 38 steps 4.41 N (450gf) in 38 steps
Instantaneous max.force (un guaranteed) 3.2 N (330gf) 4.9 N(500gf) 4.9 N(500gf)
Minimum Character size Approx 5 mm alphanumeric (varies depending on character font and type of media.
Mechanical Resolution 0.005 mm
Programmable Resolution GP-GL : 0.1 / 0.05 / 0.025 / 0.01 mm, HP-GL TM : 0.025mm
Repeatability Max 0.01 mm in plot upto 2 m +1
Mountable Numbers of Tools 1 tool
Blade Type Supersteel
Pen Type Oil-Based ball point, Water based fibre-tip pen
Media Type Self-adhesive marking film (vinyl, fluorescent, reflective) excluding high-intensity reflective film up to 0.25mm thickness polyester film up to 0.25mm thickness (un guaranteed accuracy)
Perforation cutting Yes (performed by force control)
Interface RS-232C, USB 2.0(full speed)
Buffer Memory 2MB
Command set GP-GL/HP-GL TM emulation (Set By Menu or the command, and selects from GP-GL, HP-GL TM, or auto detect)
Display Graphic type LCD with backlight (240dots x 128dots), Supports 10 languages
Registration mark sensing system Scans the mark by optical sensor (ARMS0.5), Segment area and multiple marks compensation, 4-point axis alignment, auto mark detect.
Power source 100 to 120, 200 to 240 V AC (auto switch), 50/60Hz.
Power consumption 120 VA
Operating Environment 10 to 35 C, 35 to 75% R.H. (non-condensing)
Guaranteed Accuracy Environment 16 to 32 C, 35 to 70% R.H. (non-condensing)
External Dimensions (WxDxL) Approx. 672 x 338 x 266mm Approx. 900 x 593 x 1046mm Approx. 1541 x 735 x 1250mm
Weight Approx. 10.5kg Approx. 21kg(including stand 8.1kg) Approx. 40.5kg(including stand 16.4kg)
Included Software +2 Windows Drive, Graphics Studio, Cutting Master 3, Plotter controller
Compatibility OS +2 Windows 8/ 8 pro / 7(excluding starter and home basic)/ Vista / XP / Mac OS 10.5.8 to 10.8
Compatible Standard Safety cUL, CE mark
EMC VCCI Class A, FCC Class A, EN55022 Class A
